EME
Ham Gallery - 432 MHz

This EME Ham Gallery contains info   -  incl. photos,  sound recordings, qsl cards etc. - about 70cm EME amateur radio stations. Most of them being worked or heard by the OK1TEH with single Yagi.

(inpirated by nice but unfortunately canceled web of SK0CC)

PS: FB gallery of EME stations from at OK1KIR's web & F1EHN

Temporary QRT

only hrd on 432 MHz EME
February 2006

7M2PDT's web

He head me on 432 MHz EME
April 11 2008

Phasing line is 1/2 inch heliax .TX line 15m 7/8 not seen on photo and RX line 20m 1/2 inch.

1st 432 MHz EME QSO
October 16 2012

Publisher of DUBUS Magazine for DX and construction VHF/UHF/SHF. See www.DUBUS.org and the monthly German Magazine FUNK-TELEGRAMM. See www.Funk-Telegramm.de

1st 432 MHz EME QSO
December 23 2007

1296 - 2320: 6m dish + QRO

432:
16x27 el 7,7WL LY open feed
PA 1 kW (GS23B), LNA ATF34143

1st 432 MHz EME QSO
March 28 2009

http://www.mydarc.de/dk3wg

sked possible via DL9MS

"I am now running new 8 x 28 el h. pol yagis (9WL from M²) with my "old" GS23B PA giving 1kW at the feed-point, a new LNA with NE334S01 (23 db gain and 0.2 dB NF) and TS870 and TR432H-Transverter (DB6NT)."

http://www.dl6sh.com/2.html http://moonbouncers.org/
Orebro2017/
DL6SH%20EME%20Orebro%20
2017.pdf

http://www.mydarc.de/dl7apv

1st 432 MHz EME QSO
September 8 2007

Bernd and Bodo DL7AFB in front of DL7APV's old 8x13wl Monster Ant. (source).

The crashed antenna on picture isn't 8x13wl. This was a brand new 16x7,7wl vertical group. This antenna never made a qso. The old 8x13wl is now at PA3CMCs QTH.

1st 432 MHz EME QSO
November 13 2005

Photos of DL9KR antenna.

http://ea3xu.ure.es

http://www.qsl.net/eb5eeo

http://es1rf.interval.ee/wordpress

http://es1rf.interval.ee

https://picasaweb.google.com/ES3RF

http://www.comnetsys.eu/files/ES5PC/EME

http://www.es6rq.com/en

432:
7.8 m dish, F/D 0.51, hp or lp
4CX250R Push pull 1 kW
NEC750 0.4 dB
TS790

http://pagesperso-orange.fr/f2tu

1st 432 MHz EME QSO
January 12 2009

Worked before on 70cm Meteor Scatter :)

http://www.astrorun.com/~fr5dn

Email: fr5dn<AT>izi.re

Array was destroyed by wind in 2010..

1st 432 MHz EME QSO
December 1 2007

http://www.zen70432.zen.co.uk/EME/EME_Array1.html

Email:
David.Hilton-Jones<at>clneuro.ox.ac.uk

-> EME echo on 23cm at HB9Q

1st 432 MHz EME QSO
December 15 2007

ANT: 16x26el DJ9BV
PA driver: GI7B
PA: GS35B 1.2 kW

I1NDP Home Page

I have been first licensed on Jan.1,1951 under the same call I currently hold. Initially, my main interest was DXing on the HF bands; after gaining a certain amount of experience in electronics, I have become involved in activities on the higher bands, including EME (on 432 MHz) and microwaves (up to 24 GHz). I am also interested in 160m CW DXing, a very challenging mode. Present HF equipment: ICOM 756PROIII, Alpha 76PA, 3ele steppir @50 ft., inverted l (16 radials) and beverage for 160. On the higher bands: assorted gear and antennas for 50, 144, 432 MHz, and 1.2, 2.3, 5.7, 10 and 24 GHz. I have never been too happy with the "hello-goodbye" style of QSO, and would rather have at least a few minutes' conversation with my correspondent, language barrier permitting. Professionally, I graduated from medical school in 1956 and have been a practicing physician until my retirement in 2001.

Email: asmag<AT>libero.it

ANT: 7m dish (f/d=0.5),
AZ-EL mount, dual dipole feed, switcable polarization, 1/2048 resolution, automatic Moon-tracking

JA6AHB Home Page

Email: wmccaa<at>comcast.net

Initially licensed in 1954 with a General class call of W3ZBE while living in Eastern Pennsylvania, then in 1959 with a Extra class call of K0RZJ while living in Kansas City Missouri, then in 1977 with the present call K0RZ while living in Boulder, Colorado. My Father who was my Elmer became a silent key in 1978, and held the calls of W3LCL and K0RZH. My Brother initially licensed as K3ALM now holds the call K0RZI.

The photo shows the K0RZ 432 EME antenna composed of 8 each K1FO 22 element Yagis. Each box of four Yagis can be manually rotated to either horizontal or vertical polarization in a few hours. The array is presently set for vertical polarization. The aluminum box in the center of the horizontal boom houses the Tx/Rx relays and the 0.3 NF preamp. Transmit power is 1500 Watts from an Eimac 8938. This system has been in use since 1991. CW is the preferred mode of operation.

73 Bill, K0RZ

Steve, K1FO has a
company manufacturing
RF power amps for EME
Lunar-Link

History of K1FO antenna.

Temporary QRT

http://www.brielle-nj.com/rqg/k1rqg.html
http://www.qsl.net/k1rqg/

432 & Above EME Newsletters

"I have been licensed since 1974 as WN3WMG then WA3WMG. In 1998 I changed to a vanity call K3MF. I am active on 432 MHz. EME using a Kenwood TS-2000x, a LZ2US amplifier producing about 1200 watts output to 8 x 25 K1FO yagis. My az/el control is a W2DRZ system with a homebrew az/el system. The az motor/gearbox is a 90 vdc motor running at 18 vdc for a slow and smooth rotation and the elevation motor( another 90 vdc motor) drives a modified jack screw that was once a truck jack. I use two preamps, one at the antenna and the other one at the rig. I am active on CW and JT65 modes and can take skeds as time allows."

Web: http://home.rica.net/candrus

Picture of the 70cm "array" 4x12el M2. Look close for 1/4 moon behind.

FT-100d, and power supply. Upper right with Bird watt meter on top is homebrew SSPA 300W. Also shown, Signalink USB, homebrew sequencer, Tiny Tools WRC-4 network remote control/telemetry for controlling things. Station usually operated from my home 10km away via internet.

The hill top and shack. 6m and 2m HSMS antennas behind shack. To the left is a hole just excavated for mounting the Paraclipse dish that is sitting on a trailer (future 1296/2304).

(pictures were used from K2UYH's NL)

web: http://www.k5qe.com

k6myc<at>m2inc.com

    2 pioneers from left W6DNG and K6MYC  - the West Coast VHF Conference 1967

 Web: www.elite.net/~k7xq

  On the right is my small EME array for 2m and 70cm. The antennas are InnovAntennas G0KSC LFA's. There are currently 4 18 element 432 LFA's on the left of the H-Frame and 2 15 element LFA's on the right. Justin, G0KSC designed both the antennas as well as the H-Frame for the two bands. Thus, there are two 'Splitter Bars" which you might see in the picture. They are located attached to the horizontal H-Frame bar and mounted between the vertical mast and the respective vertical H-Frame leg. The splitter-bars allow mounting the phasing harness coax as close to the LFA feed-point as possible. This obviously reduces phasing harness feedline losses. The EME pre-amps mount on the splitter bars, at the splitter for each band. Thus they too are closer to the actual driven elements than found in other methods of feeding the yagis.

The AZ/EL rotator is a Polish SPID-RAS 1.0 degree accuracy. Sometimes you see them called AlphaSPID. The control box for them to work with the computer is their "Rot 2 Prog". The tower on the right side of the picture is a Glen Martin 40 foot "Hazer", (A tram-like cage carries all of the antennas up and down the tower with an easy geared winch-crank. So I needed a Az/EL rotator which would be able to fit between the edge of the tower while still allowing the "Mast" to ride in the center of the "Hazer". The SPID-RAS fits the bill. I have lowered this assembly in high winds with no trouble. The tower has three guy-wires which I unclip, at ground level, when I am going to "possibly" need "Elevation" greater than some high number. I just walk the circle around the tower and reach over and let the end of the guy wire drop from my hand to the ground. Might take 3 minutes to grasp and drop. I have had them dropped, so far, for 38 MPH gusts and there were no structural problems. The tower is an 18 inch base version.

Rig: K3 from Elecraft with 3 transverters: XV50, XV144, XV432 ; Xref board which allows my Trimble GPS to keep the K3 on a nearly exact frequency; TCXO's and matched 8-pole filters in all.

The view is similar to the one shown from circa 060 degrees around to 280 degrees and in the Southerly direction. This is what rural Appalachia looks like to us. There are no dwellings seen, or hidden in valleys, in this picture.

http://www.qsl.net/kl6m

 1st 432 MHz EME QSO
September 8 2007

1st 432 MHz EME QSO
March 19 2010

web: http:www.naic.edu/~angel/kp4ao

email: lu7dz@yahoo.com.ar

web: http://www.lu7dz.com.ar

new antenna - February 2011 16x15el Y

http://www.qsl.net/kl6m/NewEngland/Bos4/NC1I.html

www.nr5m.com/main/page_station_tour__70_cm.html

QRT in 2008, antenna was sold.

1st 432 MHz EME QSO
June 04 2008

http://www.oe9erc.com

Now QRV only on 23cm & up

http://www.nitehawk.com/rasmit/oh2dg.html

Email: eino.metsamaki<at>sulo.fi

Other bands: 23cm 300W, 13cm 100W, +9cm 100W

History
First attempts were made in 1986 with very few qsos. The system has been under constant improvement ever since, and the current configuration is from 1997. The results in the ARRL EME contest have been around 150 qsos on 432 MHz.

Antenna
Paraboloid 16meters (55feet), f = 0,6. The mesh is normal chicken wire with 1" square ant the surface in accurate enough even on 1,2G. Look for the feed in QST, March - 88 p.12.

1st 432 MHz EME QSO
November 12 2005

Feed
Normal 2-d. In the picture on the right side you will see the white box containing the relays and preamps. This designs have been in use concerning the preamp, and the normal system in use is MGF-1300 series device in cavity construction. Nf around 0,4dB. The whole feed system can be rotated between 0 to 90 degrees. It takes about 40 seconds, so there is possible room for improvement!

Aiming
The whole antenna turns on concrete turnable 0 to 360 degrees. Elevation is limited to +58 degrees, since that is enough in our northern latitude.

TX - N7ART - made with two 3CX800A7. Output about 1kW. Feedline is 22 meters 7/8" Andrew.

Control - VK3UM system with optical encoders. Resolution 0,1 degrees.

System G: Cassiopeia noise > 6dB4

1st 432 MHz EME QSO
May 21 2015

http://ok1yk.blogspot.cz/2015/05/70-cm.html

https://picasaweb.google.com/10771673...

1st 432 MHz EME QSO
December 3 2009

http://www.ok2kjt.net/ok2poi/eme%20log.htm

1st 432 MHz EME QSO
December 23 2007

1st 432 MHz EME QSO
October 25 2010

432:
8x 14el 4.2 wl DL6WU-modified yagies 23dBd + DB6NT LNA (Micomm) 0.35dB NF + 1kW GS35B PA + TS2000X

http://www.pa0ply.nl

http://www.pa0ply.nl/eme.htm

Web: www.pa2v.com

http://www.pa3csg.hoeplakee.nl

1st 432 MHz EME QSO

                        October 27 2007

1st 432 MHz EME QSO
October 17 2008

http://www.camras.nl

http://www.camras.nl:8901

Email: jvmmap<at>bart.nl

432:
4x5.5WL 16 elements DK7ZB, ATF54143 0,3dB NF and SSPA Telefunken SV 5379 + VX432 transvertor + FT1000MP. I can measure about 8 dB sunnoise.

http://www.qsl.net/pe1rdp

70cm initials:
http://www.qsl.net/pe1rdp/init_432.htm

432:
4m dish, f/d=0.42 + patch feed
Rohde & Schwartz kW SSPA at 800W + 0,4dB NF LNA + IC-910H

[WAC WITH 1 YAGI IS COMPLETED]

432:
4,6m dish, f/d=0.37 + 650W PA
1296:
4,6m dish, f/d=0.37 + 550W PA

1st 432 MHz EME QSO
January 28 2018

1st 432 MHz EME QSO
March 11 2011

>> More pictures of antenna <<

http://lea.hamradio.si/~s53rm

Stefan, Skelleftea , Sweden
KP04NP (QRB 1662 km)
432:
IC910H+GS35B PA 1kW
P-HEMT 0,4dB NF LNA
4x32el YAGI

www.panoramio.com/user/1635829

1st 432 MHz EME QSO
February 27 2010

http://www.sm2cew.com

PHEMT cavity preamp  NF< 0.4db, 28' dish with dual dipole feed, horizontal and vertical polarization

only hrd on 432 MHz EME
27th July 2008

http://www.sm4ive.com

Web: http://sv8cs.blogspot.com

Old: 16 and 24x15el CEW + GI7BT

This my new QTH and ant 24x15el BV sun noise 16.5dB (flux 65) grnd 6.5 dB I received me echo with only 22W in feed -1.2db tx line.

201000 2 -26 2.0 -646 3 * CQ UA4API LO20

AMP: AM6154 amplifier modified/tuned for 432MHz 350w (can push to 400w for 1 or 2 sequences)

TX feedline: 100ft LDF5-50A + 12ft LMR600UF (1.1dB loss measured at power divider, not counting the relay)

ROTOR: Yaesu G5400 AZ/EL

ANTENNA: 4 x M2inc 9wl 28el/21ft boom center @ 15ft

Computer + 3 x 22"monitors

1st 432 MHz EME QSO
March 25 2006

"The male Koala spent 12 hours on Saturday in the VK3UM dish during the construction phase much to delight of the district. There are native wild Koalas in the area but this was first one observed during day light hours on out property."

1st 432 MHz EME QSO
January 25 2011

http://www.usq.edu.au/users/moat/VK4CDI.htm

VK4EME
Allan
Pomona, Australia
QG63KQ (QRB 15606 km)
432:
16x 15el (4wl) DL6WU 24dBD +
100W 1x4CX250B PA + FHX35
(0.38dB when last measured)

vk4eme<at>wia.org.au

http://www.rvhfg.org/photos/12

Bob's station utilizes the Flex 5000 SDR Transceiver, homebrew amplifiers and an array of 4 cross-polarized yagis on 144 MHz and 6 linear yagis on 432 MHz, on an AZ/EL mount.

 http://myweb.cableone.net/kj7f/

1st 432 MHz EME QSO
February 21 2010

wa2fgk<at>yahoo.com

  WA2FGK is Andy Furlong - Retired High School Electronics Teacher, and former Senior RF/Microwave Technician with Microwave Semidonductor and Anadigics Corp, is also a member of the USCG Auxiliary. Licensed since 1959. STATION MANAGER/OPERATOR: Herb Krumich, K2LNS Licensed since 1958.

We are operating from 50MHz through 10gig with the following Power Levels: 50 MHz with 1250 W, 144 MHz with 1500 W, 222 MHz with 1500 W, 432 MHz with 1500 W, 903MHz with 550 W, 1296 MHz with 300 W, 2304 MHz with 200 W, 3456 MHz with 100W, 5 GHz 16 W, 10GHz with 20 W.  FIVE Towers covering 10 Bands. Location: 2100Feet ASL Located in FN21BF Bear Creek PA.

Antennas: Number of Elements: 50 MHz - 6 over 6 over 6 over 6, 144 MHz -4 x 12 el full elevation, 222 MHz - 7 WL Yagi, 432 MHz - 4x33el Y, 903 MHz - 188 el Loop Quad, 1296MHz - 220 El Loop Quad, 2304 MHz - 288 El Loop Quad, 3456MHz - 448 El Loop Quad, 10 GHz - 30 inch Dish-Dual-Feed

wa3qpx<at>atlanticbb.net

http://www.setileague.org/photos/wa4njp.htm
